75Ω Wired Broadband RF Digital Step Attenuators

75Ω Wired Broadband RF Digital Step Attenuators

Key Features

  • High linearity, fast switching time with wide bandwidth
  • Best-in-class attenuation error with fine attenuation steps
  • Monolithic CMOS solution that integrates RF, analog and digital
  • Excellent ESD protection and reliability

RF Product Catalog

View the pSemi 2021 RF product
catalog to see our complete RF
product portfolio.

Product Store Datasheet Description Freq. Typ. IL (dB) IIP3 (dBm) Attn Range (dB) Attn Step (dB) Interface Bits Package Package (mm)
Min Max Min Max
6-bit; 64 states 1 MHz 2500 MHz 1.00 1.50 58 31.50 0.5 Parallel 6 20L QFN 4x4
6-bit; 64 states 1 MHz 2000 MHz 1.40 1.80 52 31.50 0.5 Parallel (Latched, Direct) 6 20L QFN 4x4
