RF Mixers & Limiters

RF Mixers & Limiters

Key Features

  • Exceptional performance with high-frequency support
  • Highly integrated, reliable solutions in a small form factor
  • Variety of packaging options for maximum design flexibility
  • Best-in-class ESD and reliability
pSemi Catalog

RF Product Catalog

View the pSemi 2023–2024 Product Catalog to see our complete RF product portfolio.

Power Limiters

Product Store Datasheet Description Freq. IIP3 (dBm) Adjustable Limiting Threshold (dBm) Max Power Rating (dBm) Package Package (mm) VDD Range (V) ESD HBM (V)
Min Max Min Max
Low Threshold (Limiting, Reflecting) 10 MHz 8 GHz 37 7 13 50 12L QFN 3x3 0 to 0.3 7000
Broadband (Limiting, Reflecting) 9 kHz 6 GHz 70 25 35 47 12L QFN 3x3 -2.5 to -0.5 8000

Prescalers

Product Store Datasheet Description Freq. Divide Ratio Package Package (mm) ESD HBM (V)
Min Max
Low Power 3000 MHz 13.5 GHz 4 Die - 250

Mixers

Product Store Datasheet Description Freq. Typ. Iso (dB) LO Drive (dBm) IIP3 (dBm) Package Package (mm) Conv Loss (dB) ESD HBM (V)
Min Max LO-RF LO-IF Min Max
Low Conversion Loss DC 6 GHz 25–40 25–40 +20 32 6L DFN 3x3 6.5–7.5 100
High Linearity DC 1000 MHz 40 40 +20 33 8L MSOP 3x3 7.0–8.0 100
High Linearity 136 MHz 520 MHz 43 40 –10 –6 26 10L MSOP 3x3 6.5–8.5 1000
High Linearity 136 MHz 941 MHz 30–60 22–58 –10 +23 26 20L QFN 4x4 6.5–7.5 1000

Up-Down Converters

Product Datasheet Description Freq. Package
Min Max
Dual-channel 24.25 GHz 29.5 GHz Flip-chip
