Phase Shifters
| Product | Store | Datasheet | Description | Min Freq. | Max Freq. | Typ. IL (dB) | IIP3 (dBm) | DPS Range/Step (deg) / Bits | RMS Phase Error (deg) | RMS Amplitude Error (dB) | Package | Package (mm) | Settling Time (ns) | VDD Range (V) | ESD HBM (V) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PE44820 |  |  | 8-bit DPS | 1700 MHz | 2200 MHz | 6 | 60 | 358.6/1.4/8 | 1 | 0.1 | 32L QFN | 5x5 | 365 | 2.3–5.5 | 500 |
Monolithic Phase & Amplitude Controllers (MPACs)
| Product | Store | Datasheet | Description | Min Freq. | Max Freq. | Typ. IL (dB) | P1dB/P0.1dB (dBm) | IIP3 (dBm) | DPS Range/Step (deg) / Bits | DSA Range/Step (dB) / Bits | Package | Package (mm) | Programming Mode | VDD Range (V) | IDD (mA) | ESD HBM (V) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PE46120 | | | MPAC-Doherty | 1800 MHz | 2200 MHz | 6.9 | -/35.0 | 60 | 87.2/2.8/5 | 7.5/0.5/4 | 32L QFN | 6x6 | Serial | 2.3–5.5 | 350 | 1000 |
| PE46130 | | | MPAC-Doherty | 2300 MHz | 2700 MHz | 7.2 | -/35.0 | 70 | 87.2/2.8/5 | 7.5/0.5/4 | 32L QFN | 6x6 | Serial | 2.3–5.5 | 350 | 1500 |
| PE46140 | | | MPAC-Doherty | 3400 MHz | 3800 MHz | 6.5 | -/35.0 | 60 | 87.2/2.8/5 | 7.5/0.5/4 | 32L QFN | 6x6 | Serial | 2.3–5.5 | 350 | 1500 |
| PE44951 | | Dual-channel phase shifter + DSA | 6.025 GHz | 7.525 GHz | 8.5 | 22.2-25.5 | 54.6-56 | 360 / 2.8 / 7 | 15.5 / 0.125 / 7 | 32L LGA | 5×5 | 2.3-5.5 |
Digital Tunable Capacitors (DTCs)
| Product | Store | Datasheet | Description | Min Freq. | Max Freq. | Peak RF Voltage (Vpk) | Min Typ. Shunt Capacitance (pF) | Max Typ. Shunt Capacitance (pF) | Tuning Ratio | Min Typ. Quality Factor @ Cmin | Max Typ. Quality Factor @ Cmin | Interface | Package | Package (mm) | VDD Range (V) | ESD HBM (V) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PE64102 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 6 | 1.88 | 14 | 7.4:1 | 28 | 50 | SPI | 12L QFN | 2x2 | 2.3–3.6 | 2000 |
| PE64904 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 30 | 1.1 | 5.1 | 4.6:1 | 10 | 35 | SPI | 10L QFN | 2x2 | 2.3–3.6 | 1500 |
| PE64906 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 30 | 0.9 | 4.6 | 5.1:1 | 40 | 40 | SPI | 10L QFN | 2x2 | 2.3–4.8 | 2000 |
| PE64907 | | | 5-bit; 32 states | 100 MHz | 3000 MHz | 30 | 0.85 | 2.4 | 2.82:1 | 37 | 41 | SPI | 10L QFN | 2x2 | 2.3–4.8 | 2000 |
| PE64909 | | | 4-bit; 16 states | 100 MHz | 3000 MHz | 30 | 0.6 | 2.35 | 3.9:1 | 40 | 40 | SPI | 10L QFN | 2x2 | 2.3–4.8 | 2000 |
