UltraCMOS® SPDT RF Switch

PE42724


The PE42724 is a HaRP™ technology-enhanced reflective SPDT RF switch designed for use in cable applications including DOCSIS 3.0/1 cable modem, set-top box and residential gateway. It delivers high linearity, excellent harmonics performance and high surge immunity in the 5–1794 MHz band. It also features low insertion loss and high isolation performance making the PE42724 ideal for DOCSIS 3.1 applications.

Industry-Leading Product

Specifications

DescriptionSPDT (R)
Min Freq.5 MHz
Max Freq.1794 MHz
Max Typ. IL (dB)0.40
Min Typ. IL (dB)0.10
Max Typ. Iso (dB)39
Min Typ. Iso (dB)19
P1/0.1dB (dBm)-/38.0
IIP3 (dBm)-
Package12L QFN
Package (mm)3×3

About Product

Key Features

      Supports DOCSIS 3.0/1 requirements
      Exceptional harmonics
      2fo of –121 dBc @ 17 MHz
      3fo of –150 dBc @ 17 MHz
      Best in class linearity across frequency band
      Low insertion loss and high isolation performance
      Insertion loss of 0.3 dB @ 1218 MHz
      Isolation of 39 dB @ 204 MHz
      Packaging: 12-lead 3 × 3 × 0.75 mm QFN
